Belt attachment base - Mounts on rear of carriage assembly - Covers carriage PC board and holds belt attachment tower
Paper drive assembly bracket - Paper drive motor, cluster gear and the encoder PC board all mount to this item
Replacement duplexer module assembly - installs in rear of printer (in place of the rear clean out door assembly) - for performing two-sided printing.
IEEE 1284 Bi-Tronics parallel cable - DB-25 (M) connector (type A) to 36-pin high density IEEE 1284C (M) connector (type C) - 3.0m (9.8ft) long -- Mini Connector
IEEE 1284 Bi-Tronics parallel cable - DB-25 (M) connector (type A) to 36-pin high density IEEE 1284C (M) connector (type C) - 10m (33ft) long
Control panel assembly with buttons (Does NOT include bezel)
Cover - For rear paper cleanout door assembly
Rear cleanout door assembly - Paper jam cleanout door
Fax module assembly - Provides fax capabilities for the OfficeJet (Includes LIU connector)
Feed roller idler gear
Cluster gear for HP OfficeJet K60
Lower paper guide housing (Does NOT include any attaching parts)
Inner paper guide (Includes antistatic brush) - Guides the paper through the print mech and over the upper paper guide
Kicker bar - Restacks paper in paper input tray stack after the top sheet is picked
Kicker bar cam link (spring loaded)
Carriage motor assembly (Includes pulley)
Paper drive motor assembly - Includes pulley
Pallet/link assembly - Installed between spittoon and sled cap assembly - Mounting platform for the wiper and capping systems parts
HP Delux Advance Glossy Photo Paper 25 sheets of A size HP Advanced glossy photo paper
Interconnect PC board (L-SHAPED) - Interconnects the scanner assembly to the main logic board - Also has the paper and door sensors
Interconnect PC board - Small square PC board with four contact pads for the duplexer module
Power cord (Black) - 2.0m (6.6ft) long - Has straight (F) C13 receptacle (For 240V in India)
Flag and cable assembly - Media sensor
Slider for carriage assembly - Rides along the upper guide rail on the print mechanism chassis
Pinch spring - Provides tension on upper paper guide
Lifter spring - Provides upper tension on the kicker bar (cam follower) lift plate
Upper paper guide support - Support bracket which attaches to the print mech frame for mounting the upper paper guide
Glass assembly support - Retains the scanner glass inside the scanner bezel
Belt attachment tower - Used to attach the carriage belt to the carriage assembly
Cap vent - For equalizing the print cartridge capping pressure
Right wingframe assembly - Supports paper from the print mechanism prior to exiting to the paper tray frame assembly
Left wingframe assembly - Supports paper from the print mechanism prior to exiting to the paper tray frame assembly
