Belt attachment base - Mounts on rear of carriage assembly - Covers carriage PC board and holds belt attachment tower
HP Business Inkjet 2250TN Printer
HP Business Inkjet 2250 printer
Control panel/keypad and display assembly (New style) - Has edge connector socket for control panel cable
Scanner cover assembly (Upper ADF) - Covers the scanner glass - Helps to feed documents over the scanner assembly - Has hard black plastic rollers
Kicker bar - Restacks paper in paper input tray stack after the top sheet is picked
Sensor PC board - Contains optical media sensors and mechanical switch for access door
Carriage PC board - Contains the print cartridge control circuitry - For Japan only
Main Logic Pca Dj95xc 4m
Paper drive assembly encoder PC board
Lamp driver PC board - Drives the scanner lamp
Old#c6659-60150/ Pca-Main Oj700/710/720
Main Logic PC Board (Does NOT Include Groundplane/Mounting (NO EXCHANGE)
Power module (universal / worldwide) - Input voltage 100-240VAC 1500mA - Output voltage 32VDC 1560mA - Requires a separate detachable AC power cord with C13 connector
PWR-SPLY-AC-DC ADAPTER; 50W ROHS Power module - Input voltage 100-240VAC 50/60Hz - Output voltage 32VDC 1.56A 50 watts - Requires separate 3-wire AC power cord with C-13 connector (not included).
Power Supply : Power supply assembly - Does not include rear panel power socket/power cable assembly
Power Supply PC Board
Power supply assembly - Does not include rear panel power socket/power cable assembly
Right wingframe assembly - Supports paper from the print mechanism prior to exiting to the paper tray frame assembly
