ADF Automatic Document Feed Assembly paper feeder
Cartridge access top cover - Protects carriage and printer mechanism
Fuser rear cover - Protects the fuser assembly - Located on the top rear side of the printer
Top cover assembly - Protects the top part of the printer chassis
Front cover assembly - Covers the front and top center of the printer
Right cover - Plastic cover that protects the right side of the printer
ADF paper seperation pad assembly - Mounts in the center of the ADF separation pad frame assembly at the rear of the paper input tray
Separation pad assembly - Located on the paper pick-up assembly
Formatter (Main logic) board - For HP LaserJet M1522nf MFP series - For copy models only (CC368-60001 for fax models).
SHAFT ADF pickup roller assembly - Includes *black shaft frame that pickup rollers attach to and both pickup rollers Automatic document feeder (ADF) paper pick-up roller assembly
D-shaped pick-up roller - Located on the paper pick-up assembly
Transfer roller assembly - Long metal shaft with black roller
Flatbed scanner assembly - For Color LaserJet M1522 MFP - Includes flatbed scanner frame and glass
M3 pan-head Phillips screw - 10mm long
Internal speaker - Located on the left side of the printer
Compression spring - Provides pressure for scanner link - Two used, one on each side
