Airflow Guide (duct) - Black plastic insert piece which runs the width of the printer and has an air flow hole on right side
Airflow guide (duct) / fan holder bracket assembly (Quartz Gray plastic)
Right roller bushing - Acts as the bearing and retainer for the right end of the paper pickup roller assembly (tray 1)
Bushing/shaft retainer assembly (White plastic)
Bushing for HP Color LaserJet 1500 Series
Flat flexible cable (FFC) assembly - Connects between the formatter assembly (J1001) and the DC controller board (J101)
Cable assembly (two 2-pin connectors)
Cable assembly (two 8-pin connectors, Purple wire)
Cable assembly (two 7-pin connectors)
Cable assembly (two 5-pin connectors)
High voltage cable assembly
High voltage cable assembly (two 15-pin connectors and two 14-pin connectors)
Cable assembly (two 3-pin connectors and a spad lug)
Toner cleaning cloth - Specially treated cloth for absorbing toner or Ink (1 per package) - Ideal for cleaning up toner spills and Ink for your plotter / copier / printer
Cable clip - `C` shaped White plastic
Drawer connector - Connector located on bottom of tray assembly frame on right side, which connects tray assemblies to each other
Control panel assembly (mechanical only) - Includes the 'Rotate Carousel', 'Cancel Job' and the 'Go' buttons, plus the various indicator light pipes - All switches and LED's are on the formatter PC board
Upper rear cover (Quartz Gray) - Mounts on the upper rear of the printer above the face-up output tray door
Gear Cover (Small Black plastic cover) - Covers the left end of the feed drive shaft
Roller cover - Covers the multipurpose paper pickup roller assembly - Mounts on the lower front of the front frame assembly
Solenoid cover (Steel) - For magnetic wave sheilding
Damper assembly (Gray plastic piece with small 13-tooth gear on it)
Rotary drive assembly - Includes the carousel rotating motor (DCM703), toner cartridge drive motor (PM705), developing rotary stopper solenoid (SL93), bracket, and gears
Sensor arm and flag - Activates the photosensor (Does NOT include the roller)
Test print flag (Black lever)
Fuser Assembly (For 110V to 127V operation) - Bonds the toner to the paper with heat
22 tooth gear (Black plastic) - Small gear with diagonally cut teeth
Gear assembly - Metal plate with two White plastic gears attached
26 tooth gear (Black plastic) - Has 1/8th portion of gear cut away
Dual gear - 20 tooth / 40 tooth
30 tooth gear (White plastic)
Dual gear - 26 tooth / 50 tooth (White plastic)
26 tooth gear (White plastic) - Has recess for shaft drive pin
Dual gear - 32 tooth / 37 tooth (White plastic)
Dual gear - 37 tooth / 43 tooth (White plastic)
51 tooth gear (White plastic)
Cable guide (Quartz Gray plastic)
Left paper feed guide (small Black plastic arm)
Right paper feed guide (small Black plastic arm)
Left cartridge guide assembly
Sensor assembly mounting holder
Holder - Housing for the fusing connector assembly
Interlock switch holder (Quartz Gray plastic) - Does NOT include the micro-switch
Insulating sheet (Transparent plastic)
Laser/scanner assembly
Right side lock release lever
Left side lock release lever
Stepping motor (24V)
Stepping motor - 24VDC
Separation pad assembly - Includes the separation pad, holder and spring
Top of page photoelectric sensor PC board - Includes the photoelectric top of page sensor and the print engine test switch
Density photoelectric sensor PC board
HP JetDirect 380X external IEEE-802.11b (Wi-Fi) wireless print server - Connects to printer using Universal Serial Bus (USB) cable
Mounting/grounding plate
Transfer slide plate - Small 'U' shaped metal insert plates
Contact plate - copper clad metal spring - Holds the left end of the small 500 Meg-ohm resistor
Contact plate - copper clad metal spring - Holds the right end of the small 500 Meg-ohm resistor
Contact plate for HP Color LaserJet 2500 Seriess
Sub-high voltage board - Small auxillary PC board
Pulley roller (accommodates three feed belts) - Small black roller approximately 3.49cm (1-3/4 inches) long with three ball type pulleys
Pulley roller (accommodates one feed belt) - Small black roller approximately 1.59cm (5/8 inch) long with one ball type pulley
Sensor flag roller (small White plastic roller)
Pressure roller (small Black hard plastic disk shaped roller)
Pressure roller (small Black hard plastic 'solid' roller)
Paper pickup roller ('D' shaped)
Lock release shaft - Small shaft with locking tab - Does NOT include the lock release lever
RFI shield - Parallel wire form mounted over the fan
Registration shutter assembly - Includes the metal roller, mounting frame, grounding springs, and the dual coupling gear
Torsion spring for HP Color LaserJet 2500 Series
Compression spring
Electrical contact spring - Spring steel wire with compression springs formed on both ends
Electrical contact spring
Right retaining spring - Helps to secure and ground the imaging drum/transfer assembly in the printer
Left retaining spring - Helps to secure the imaging drum/transfer assembly in the printer
Tension spring for HP Color LaserJet 1500 Series
PC board support (Black plastic holder)
Microswitch with lever activator
Thermistor for HP Color LaserJet 2820 Series
